Orca Multifunctional Receiver and Spectrum Analyzer

Orca Multifunctional Receiver image

Orca Spectrum Analyzer image

Orca is a high-performance, real time radio signals receiver and spectrum analyzer built on software-defined radio (SDR) technologies. Its main parameters are:

Input frequency range : 50 MHz – 6,2 GHz;
Frequency measurement accuracy: ± 0.25 ppm;
Level measurement accuracy: ± 2 dB;
Spectrum analyzer (FFT) and receiver (IQ);
Sensitivity in the 1 kHz measurement band: at least minus 101 dBm;
Setting frequency step: 1 kHz;
Dynamic range: not less than 87 dB;
Suppression of side channels of reception: not less than 40 dB;
Operating temperature range from minus 10 to 50 deg. C;
Maximum permissible humidity: up to 95%;
IP41 protective shell;
Control over TCP / IP, Ethernet 1Gbit.
